Single-Ply & 3-Ply Hollow Core Classic Baffles

Style: Aileron

8 Foot Version

4 Foot Version

Style: Stealth

Dimensions Custom to Project

Single-Ply & 3-Ply Hollow Core Baffle Cut Sheet Check Our Custom Baffles

Style: Wind

8 Foot Version

4 Foot Version

Style: Sound Waves

Series A

Series B

Specifications:

Category: Baffles

Subcategory: Classic Baffles

Construction: Singly-Ply & 3-layer PET Felt, Hollow Core

Styles: 8' & 4' Baffles

Size: 11.5" H x 95" L & 11.5" H x 47" L

Color: Click to View PET Acoustic Felt Color Options

Fire Rating: ASTM E84 CLASS A

Sabins: 6 - 8+ (A, B), 12 - 16+ (C-F)

NRC: 0.75 - 1.0+

Available Thicknesses: 9mm (3/8"), 12mm (1/2"), & 24mm (1")

Location: Ceiling

Mounting Method:

Cable Suspended

Hardware:

Included (Please Indicate Substrate)

Fuse

Available Lengths: 48", 72", 96", 108"

Available Widths: 2" or 3"

Available Heights: 5" or 6"

Fuse Baffle Cut Sheet

Specifications:

Category: Clouds

Name: Fuse

Styles: Baffles in Various

Dimensions

Sizes: 2-8" W x 6-11.5" H x 47-95" L

Color: Click to View PET Acoustic Felt Color Options

Fire Rating: ASTM E84 CLASS A

Sabins: 96 - 104

NRC: 1.25

Available Thicknesses: 9mm (3/8"), 12mm (1/2"), & 24mm (1")

Location: Ceiling

Lighting Option: LED Beam Downlight or Down/Uplight - Both Optional (upcharge)

Mounting Method:

Cable Suspended

Hardware:

Included (Please Indicate Substrate)

Fuselage

Available Lengths: 47", 72", 95", 107"

Available Widths: 1.5", 2", 3" or Custom

Available Heights: 5", 6", 8" or 12"

Fuselage Baffle Cut Sheet

Specifications:

Category: Clouds

Name: Fuselage

Styles: Box Beam Baffles in Various Dimensions

Sizes: 2-8" W x 6-11.5" H x 47-95" L

Color: Click to View PET Acoustic Felt Color Options

Fire Rating: ASTM E84 CLASS A

Sabins: 96 - 104

NRC: 1.25

Available Thicknesses: 9mm (3/8"), 12mm (1/2"), & 24mm (1")

Location: Ceiling

Lighting Option: LED Beam Downlight or Down/Uplight - Both Optional (upcharge)

Mounting Method:

Cable Suspended

Hardware:

Included (Please Indicate Substrate)

UAP (Folded 2-Layer)

Available Lengths: 48", 72", 96", 108"

Available Heights: 22", Custom

UAP Baffle Cut Sheet

Specifications:

Category: Clouds

Name: Fuselage

Styles: Box Beam Baffles in Various Dimensions

Construction: Folded 2-Layer Felt2 2

Sizes: 2-8" W x 6-11.5" H x 47-95" L

Color: Click to View PET Acoustic Felt Color Options

Fire Rating: ASTM E84 CLASS A

Sabins: 96 - 104

NRC: 1.25

Available Thicknesses: 9mm (3/8"), 12mm (1/2"), & 24mm (1")

Location: Ceiling

Lighting Option: LED Beam Downlight or Down/Uplight - Both Optional (upcharge)

Mounting Method:

Cable Suspended

Hardware:

Included (Please Indicate Substrate)

UAP Baffles (Ganged Together in 24' L)

Single-Ply & 3-Ply Hollow Core

Learn more

Fuse

Here's all you do

Write a description for this tab and include information that will interest site visitors. For example, if you are using tabs to show different services, write about what makes each service unique. If you are using tabs to display restaurant items, write about what makes a specific dish particularly worthwhile or delicious.

Learn more

Fuselage

Smooth & moisturized

Learn more

UAP (Folded 2-Layer)

Item Link

MACH Series

Our MACH Series product is often used on existing acoustic grid, attaching mechanically or via rare-Earth magnets. It can also be added as a floating grid design element (shown here) to mitigate reverb/echo and add a dramatic aesthetic to a space.
